CMU 16726 Learning Based Image Synthesis

Sergei Mikhailovich Prokudin-Gorskii (1863-1944) envisioned colored photography and recorded three exposures of every scene onto a glass plate using a red, a green and a blue filter.

In this project, the glass plate images are processed and used to produce colored images.

1.2 Methods

- For alignment, first aligning red to green, then blue to green, and then stacking the three channels (aligned red, aligned blue, green) together. Most of the images have the same brightness across all color channels, aligning the other 2 channels with the third will work, except for the emir image, in which the green channel has a different brightness level from the other two.

- First I tried the single-scale alignment, it performs better on low-res images, but is extremely slow and performs poorly on high-res images, as we are only shifting once and computing brightness SSDs across all the image pixels, which has too much details and can fail to produce an approximately correct shifting

- Then I used multi-scale pyramid method, first down-scaling the high-res images to a tiny image, compute SSD and shift to align, then up-scale the image by a constant, again compute SSD and shift the color channels to align with each other. This is repeated until the image is up-scaled back to the original size. We shift the image several times, and with each up-scaling, the new shifting is a finer-tuned shift. This method is much quicker than the single-scale one, and performs quite well on almost all images

2. Results

2.1 Single-scale implementation with successful results on low-res images

2.2 Multiscale pyramid version that works on the large images

This is due to the Emir image's green channel having a different brightness level than others channels.

To solve this, I instead aligned the two other channels to green and solved the problem. The new aligned Emir image can be seen at the end of this subsection

Self-portrait

Lady

Emir

Three generations

Icon

Turkmen

Village

Train

Cathedral

Harvesters

Emir misalignment

Aligned Emir image

2.2.2 Comparison between multiscale pyramid version single scale

Self-portrait with single-scale alignment

Self-portrait with multiscale pyramid method

Turkmen with single-scale alignment

Turkmen with multiscale pyramid method

2.3 My own choice of images downloaded from the Prokudin-Gorskii collection

Data source

Image 00453a

Image 00472a

Image 00434a

Image 00447u

Image 00729u

Image 00777u

3. Bells & Whistles (Extra Credit)

3.1 Pytorch reimplementation

3.2 Automatic contrasting

I rescaled the brightness level to minimum = 0 and maximum = 1, then I scaled the brightness by a constant, scaling up the ones above the average value, and scaling down the ones below, depending on the brightness level itself and color channels. The values are finally clipped between [0, 1]
